Pumps-by Aquascape-Tsurumi PN/PU Pumps

Tsurumi Submersible Pumps for Professional Water Feature Applications are energy efficient pumps and designed for continuous duty applications, known for their reliable operation.

Tsurumi's PN series pumps have had a successful presence in the water feature market for close to a decade. The PN series provides a good match for ponds with higher heads or require a vertical style pump housing

All PN/PU pumps have a suggested pipe diameter of 2" and have a 2" female discharge and run on 115v.

Dimensions of 3PN, 4PN, 8PN: 15 7/8" Tall x 9 5/8" Wide x 6 11/16" Diameter Cylinder

New 12PN Pump from Tsurumi

Aquascape is excited to announce the debut of the new 11,500 GPH 12PN pump from Tsurumi. The 12PN is designed for water features that use Large Snorkels(tm) and Grande Skimmers. Tsurumi's engineers have hydraulically designed the new 12PN for operation on water feature projects with as little as 1-foot of head. This makes specifying projects very easy, since there is no concern about low-end operating ranges. The 12PN pump includes a 3-inch discharge making this pump an interchangeable option with the AquascapePRO(tm) 10,000 pump. The 12PN is easy to install and service due to its compact and light-weight design.


Tsurumi 12PN Fast Facts:

*Max Flow Rate - 11,500 gph
*Hydraulic design allows the pump to be operated with as little as 1-ft of head
*Best Efficiency Point- 7,000 gph @ 11 ft of head
*3-inch discharge makes it Interchangeable with AquascapePRO(tm) 10,000
*Durable cast iron volute, stainless housing and fiberglass reinforced plastic cap
*Excellent energy efficiency in its class - 1032 Watts = $75.29/mo operating cost*
*Compact and light-weight - 15" H x 11 5/8" W x 7 11/16" and 31.9 lbs
*2-Year Warranty

NOTE: If converting from Aquascape Pro 3000, 4500, 7500 pumps to Tsurumi - Must have Check Valve Tsurumi Adpter Kit #29652 to enable Tsurumi to fit in Aquascape Skimmer

In '09 we will be selling maintenance kits for the Tsurumi pumps so you can change/add oil to the pump (not needed in the first few years). It will have simple instructions. The pump should be stored in water to assure that the seals do not dry out, but should be started while still submerged in the water for a few seconds during the winter months so the barrier between the seals and shaft do not fuse together

Pump Performance

Model	Discharge	Watts	Monthly Op Cost	Max Head Height	5'	10'	15'	20'	25'	30'	35'	40'
8PN	2" Female	924	$64.46	56'	5520	5400	5340	4800	4200	3600	3000	1800
12PN	3" Female	1032	$75.29	23'	10,000	7500	4500	1500	1080
